airScope X100V AMP is a 1or 2 multizone Streamer & High Voltage amplifier, that allows users to stream different HiFi music from their favorite smart devices, such as android phone or tablet, iPhone, iPad, Mac or personal PC, to four independent zones simultaneously. Besides play personal local library, airScope X100V AMP also provide massive online music or tunes services for our users, such as Spotify, Pandora, iHeartRadio, TuneIn, Tidal, and more service will coming by global online update, which offers our users get access to millions of music and tunes.
airScope X100V AMP is a 100W constant power amplifier consisting of a power unit and an amplifier unit, designed for distributed speaker systems like background music system, alarm system, broadcast system and so on. It can continuously output 70V/100V RMS directly with no need of an output transformer, which means you can connect the output directly to the distributed speakers with transformers. airScope X100V AMP features high reliability and stability, guaranteed by equipped full protection circuit, perfectly applicable to high demanding commercial and industrial applications.
Transformer-less 70V/100V RMS Output
airScope X100V AMP can directly continuously deliver 70V/100V RMS without need of an output transformer, highly reducing the weight and size, and improving frequency response and distortion which could be negatively influenced by the output transformer. You can connect X100V AMP to the distributed speakers directly, greatly simplifying the installation and integration procedure.
Supporting Both Constant Voltage and Constant Resistance Mode
In addition to default constant voltage mode for mass notification system, airScope X100V AMP supports driving a low impedance speaker for local audio playback as well, improving the flexibility and expandability of the whole system. The switching of the two modes is extremely simple. We left a position on the X100V AMP for switching. You only need to enable this position with a high level voltage.
Wide Power Supply Range as 90VAC-254VAC
airScope X100V AMP supports wide power supply range as 90VAC-254VAC. Therefore, it supports universal main power as 110VAC and 220VAC. High quality industrial terminals are installed on X100V AMP. You just need to connect power to X100V AMP and wait for its start, no need for any other operations.
Two Levels Gain Adjustable
airScope X100V AMP provides two levels gain for your selection, high level gain as 37.7dB (80V/V) and low level gain as 32dB (40dB). There is a switch on X100V AMP for the adjustment of gain level. The output voltage is determined by both input audio voltage and the gain.
Easy Control Functions
In order to help customers easily control the system, we equipped airScope X100V AMP with necessary control functions. We all know X100V AMP is a power amplifier composed of a power unit and an amplifier. The two units can be shutdown separately. X100V AMP supports half power control, which means once the function is enabled, the output voltage of the power unit will decrease from ±72V to ±56V for lower power consumption.
Full Protection for High Reliability
Bearing the strict requirements of distributed speaker system on reliability and stability in mind, we developed airScope X100V AMP with full protection circuit (OTP, OVP, UVP, DC Bias Protection) to ensure it can run stably for long time. In addition, all X100V AMP need to pass through a series of rigorous tests like HASS and HALT test before storing in the warehouse. All the test data are recorded. Furthermore, if you have special requirements on tests, please contact us for further discussion.
airScope X100V AMP is an innovative multizone streamer (1 or 2 independent audio streamers – amplifiers 2 or 4 x 100 W for one zone) for building 2 or 4 zones Sound System. Just connect the system to Your home Wi-Fi or wired network. The specialized iOS and Android applications offer you the easiest way to set up a Wireless Multi-Zone Sound System. X100V AMP also provides the most powerful playback option, which allows You to stream synchronized music or different music from cellphone/online music service/NAS/UPNP Network & Airplay in multiple rooms with a perfect sound.
Wi-Fi connectivity – it is easy to build Your own multizone audio system, to stream music to different zones and to control playback independently for each of zones. Mobile Music – wirelessly play the music from Your mobile phones. Online Music – Search and listen to free online music through the app. Internet Radio – mobile control app pre-loaded with TuneIn, more than thousand of free radio stations. airScope Favorites – Save favourite songs and create Your personal playlist. Quick start from the main menu. Airplay Function – For iOS system (iPhone, iPad, iMac) smart devices: choose Airplay function and play any music you want without app. DLNA Function – Wirelessly stream audio by DLNA function. Line In – streamer in each of zones has an integrated audio input for connecting external audio sources.
airScope X100v AMP Specification
[table “1616” not found /]
Wi-Fi connectivity
Each audio system launches wifi signal and you can easily configurate your music system.
Hi-Fi Sound
Enjoy your Hi-Fi music.
Multi-room System
Configurate your own music system, stream same music to different zones or even stream different music to separate zones.
Mobile Music
Wirelessly play the music stored on your mobile phones.
Online Music
Search and listen to free online music through the app.
Internet Radio
Mobile control app pre-loaded with TuneIn, more than thousands of free radio stations.
Airplay Function
With iOS system (iPhone, iPad, iMac) smart device, choose Airplay function and play any music you want without app
DLNA Function
Wirelessly stream the sound by DLNA function.
Massive Music Services
Spotify
Pandora
Tunein
iHeart Radio
Tidal
Drivers for Partnership in Automation
One of the things that makes airScope audio systems different from consumer products is the partnership that we have established with automation companies.
The ability to work well with the automation system brings consumers good music service experience. One of our strategies is to invest more to make airScope work as seamlessly as possible with more automation system.
If you are looking to develop more drivers for airScope products, please send us email: air@filmoscope-lab.com, we will contact you as soon as possible.
Available: HDL BUS, KNX, FIBARO, CONNECT HOME
More systems aviable in future…
Control App for Android
The Control App turns your smart phone or tablet into a remote control to enjoy your music everywhere in your home. Play, control and explore your music, all in one App.
The Control App turns your smart phone or tablet into a remote control to enjoy your music everywhere in your home. Play, control and explore your music, all in one App.
